Demo Units

Demo Filtering Kit

For quick and easy filter testing, this demo filtering kit provides multiple frequency control modes, auto-detection of filter type, inserted between PC and filter evaluation card. Simple software setup. No-cost loan.

Computer Requirements:

• A computer with Windows 10 or higher running 32-bit or 64-bit , earlier operating systems are not supported

• A USB 1.1/2/3 port

• The .NET framework 4.0

• A monitor with a resolution of at least 800 x 600 (SVGA)

• The latest FTDI VCP drivers found here: http://www.ftdichip.com/Drivers/VCP.html

Demo Filter Controller User Manual

IMF Demo Instructions
